pain.001.001.10 type reference (part 3 of 3)

Complex types in ISO 20022 pain.001.001.10, generated from the official XSD. Part 3 of 3: PostalAddress24 – TaxRecordDetails2.

Part 1 · Part 2 · Part 3

Each type is defined once here. The message structure repeats a party or address block under every party; this view does not, which is what you want when mapping source fields.

A choice type means the children are alternatives: supply one, not all. Cardinality in bold is required.

`PostalAddress24`#

Element	Card.	Type	Constraints
`AdrTp`	0..1	`AddressType3Choice`
`Dept`	0..1	`Max70Text`	length 1–70
`SubDept`	0..1	`Max70Text`	length 1–70
`StrtNm`	0..1	`Max70Text`	length 1–70
`BldgNb`	0..1	`Max16Text`	length 1–16
`BldgNm`	0..1	`Max35Text`	length 1–35
`Flr`	0..1	`Max70Text`	length 1–70
`PstBx`	0..1	`Max16Text`	length 1–16
`Room`	0..1	`Max70Text`	length 1–70
`PstCd`	0..1	`Max16Text`	length 1–16
`TwnNm`	0..1	`Max35Text`	length 1–35
`TwnLctnNm`	0..1	`Max35Text`	length 1–35
`DstrctNm`	0..1	`Max35Text`	length 1–35
`CtrySubDvsn`	0..1	`Max35Text`	length 1–35
`Ctry`	0..1	`CountryCode`	pattern `[A-Z]{2,2}`
`AdrLine`	0..7	`Max70Text`	length 1–70

`ProxyAccountIdentification1`#

Element	Card.	Type	Constraints
`Tp`	0..1	`ProxyAccountType1Choice`
`Id`	1..1	`Max2048Text`	length 1–2048

`ProxyAccountType1Choice` (choice: supply one)#

Element	Card.	Type	Constraints
`Cd`	1..1	`ExternalProxyAccountType1Code`	length 1–4
`Prtry`	1..1	`Max35Text`	length 1–35

`Purpose2Choice` (choice: supply one)#

Element	Card.	Type	Constraints
`Cd`	1..1	`ExternalPurpose1Code`	length 1–4
`Prtry`	1..1	`Max35Text`	length 1–35

`ReferredDocumentInformation7`#

Element	Card.	Type	Constraints
`Tp`	0..1	`ReferredDocumentType4`
`Nb`	0..1	`Max35Text`	length 1–35
`RltdDt`	0..1	`ISODate`
`LineDtls`	0..*	`DocumentLineInformation1`

`ReferredDocumentType3Choice` (choice: supply one)#

Element	Card.	Type	Constraints
`Cd`	1..1	`DocumentType6Code`	16 codes
`Prtry`	1..1	`Max35Text`	length 1–35

`ReferredDocumentType4`#

Element	Card.	Type	Constraints
`CdOrPrtry`	1..1	`ReferredDocumentType3Choice`
`Issr`	0..1	`Max35Text`	length 1–35

`RegulatoryAuthority2`#

Element	Card.	Type	Constraints
`Nm`	0..1	`Max140Text`	length 1–140
`Ctry`	0..1	`CountryCode`	pattern `[A-Z]{2,2}`

`RegulatoryReporting3`#

Element	Card.	Type	Constraints
`DbtCdtRptgInd`	0..1	`RegulatoryReportingType1Code`	3 codes
`Authrty`	0..1	`RegulatoryAuthority2`
`Dtls`	0..*	`StructuredRegulatoryReporting3`

`RemittanceAmount2`#

Element	Card.	Type
`DuePyblAmt`	0..1	`ActiveOrHistoricCurrencyAndAmount`
`DscntApldAmt`	0..*	`DiscountAmountAndType1`
`CdtNoteAmt`	0..1	`ActiveOrHistoricCurrencyAndAmount`
`TaxAmt`	0..*	`TaxAmountAndType1`
`AdjstmntAmtAndRsn`	0..*	`DocumentAdjustment1`
`RmtdAmt`	0..1	`ActiveOrHistoricCurrencyAndAmount`

`RemittanceAmount3`#

Element	Card.	Type
`DuePyblAmt`	0..1	`ActiveOrHistoricCurrencyAndAmount`
`DscntApldAmt`	0..*	`DiscountAmountAndType1`
`CdtNoteAmt`	0..1	`ActiveOrHistoricCurrencyAndAmount`
`TaxAmt`	0..*	`TaxAmountAndType1`
`AdjstmntAmtAndRsn`	0..*	`DocumentAdjustment1`
`RmtdAmt`	0..1	`ActiveOrHistoricCurrencyAndAmount`

`RemittanceInformation16`#

Element	Card.	Type	Constraints
`Ustrd`	0..*	`Max140Text`	length 1–140
`Strd`	0..*	`StructuredRemittanceInformation16`

`RemittanceLocation7`#

Element	Card.	Type	Constraints
`RmtId`	0..1	`Max35Text`	length 1–35
`RmtLctnDtls`	0..*	`RemittanceLocationData1`

`RemittanceLocationData1`#

Element	Card.	Type	Constraints
`Mtd`	1..1	`RemittanceLocationMethod2Code`	6 codes
`ElctrncAdr`	0..1	`Max2048Text`	length 1–2048
`PstlAdr`	0..1	`NameAndAddress16`

`ServiceLevel8Choice` (choice: supply one)#

Element	Card.	Type	Constraints
`Cd`	1..1	`ExternalServiceLevel1Code`	length 1–4
`Prtry`	1..1	`Max35Text`	length 1–35

`StructuredRegulatoryReporting3`#

Element	Card.	Type	Constraints
`Tp`	0..1	`Max35Text`	length 1–35
`Dt`	0..1	`ISODate`
`Ctry`	0..1	`CountryCode`	pattern `[A-Z]{2,2}`
`Cd`	0..1	`Max10Text`	length 1–10
`Amt`	0..1	`ActiveOrHistoricCurrencyAndAmount`
`Inf`	0..*	`Max35Text`	length 1–35

`StructuredRemittanceInformation16`#

Element	Card.	Type	Constraints
`RfrdDocInf`	0..*	`ReferredDocumentInformation7`
`RfrdDocAmt`	0..1	`RemittanceAmount2`
`CdtrRefInf`	0..1	`CreditorReferenceInformation2`
`Invcr`	0..1	`PartyIdentification135`
`Invcee`	0..1	`PartyIdentification135`
`TaxRmt`	0..1	`TaxInformation7`
`GrnshmtRmt`	0..1	`Garnishment3`
`AddtlRmtInf`	0..3	`Max140Text`	length 1–140

`SupplementaryData1`#

Element	Card.	Type	Constraints
`PlcAndNm`	0..1	`Max350Text`	length 1–350
`Envlp`	1..1	`SupplementaryDataEnvelope1`

`TaxAmount2`#

Element	Card.	Type	Constraints
`Rate`	0..1	`PercentageRate`	10 decimals max
`TaxblBaseAmt`	0..1	`ActiveOrHistoricCurrencyAndAmount`
`TtlAmt`	0..1	`ActiveOrHistoricCurrencyAndAmount`
`Dtls`	0..*	`TaxRecordDetails2`

`TaxAmountAndType1`#

Element	Card.	Type	Constraints
`Tp`	0..1	`TaxAmountType1Choice`
`Amt`	1..1	`ActiveOrHistoricCurrencyAndAmount`

`TaxAmountType1Choice` (choice: supply one)#

Element	Card.	Type	Constraints
`Cd`	1..1	`ExternalTaxAmountType1Code`	length 1–4
`Prtry`	1..1	`Max35Text`	length 1–35

`TaxAuthorisation1`#

Element	Card.	Type	Constraints
`Titl`	0..1	`Max35Text`	length 1–35
`Nm`	0..1	`Max140Text`	length 1–140

`TaxInformation7`#

Element	Card.	Type	Constraints
`Cdtr`	0..1	`TaxParty1`
`Dbtr`	0..1	`TaxParty2`
`UltmtDbtr`	0..1	`TaxParty2`
`AdmstnZone`	0..1	`Max35Text`	length 1–35
`RefNb`	0..1	`Max140Text`	length 1–140
`Mtd`	0..1	`Max35Text`	length 1–35
`TtlTaxblBaseAmt`	0..1	`ActiveOrHistoricCurrencyAndAmount`
`TtlTaxAmt`	0..1	`ActiveOrHistoricCurrencyAndAmount`
`Dt`	0..1	`ISODate`
`SeqNb`	0..1	`Number`	0 decimals max
`Rcrd`	0..*	`TaxRecord2`

`TaxInformation8`#

Element	Card.	Type	Constraints
`Cdtr`	0..1	`TaxParty1`
`Dbtr`	0..1	`TaxParty2`
`AdmstnZone`	0..1	`Max35Text`	length 1–35
`RefNb`	0..1	`Max140Text`	length 1–140
`Mtd`	0..1	`Max35Text`	length 1–35
`TtlTaxblBaseAmt`	0..1	`ActiveOrHistoricCurrencyAndAmount`
`TtlTaxAmt`	0..1	`ActiveOrHistoricCurrencyAndAmount`
`Dt`	0..1	`ISODate`
`SeqNb`	0..1	`Number`	0 decimals max
`Rcrd`	0..*	`TaxRecord2`

`TaxParty1`#

Element	Card.	Type	Constraints
`TaxId`	0..1	`Max35Text`	length 1–35
`RegnId`	0..1	`Max35Text`	length 1–35
`TaxTp`	0..1	`Max35Text`	length 1–35

`TaxParty2`#

Element	Card.	Type	Constraints
`TaxId`	0..1	`Max35Text`	length 1–35
`RegnId`	0..1	`Max35Text`	length 1–35
`TaxTp`	0..1	`Max35Text`	length 1–35
`Authstn`	0..1	`TaxAuthorisation1`

`TaxPeriod2`#

Element	Card.	Type	Constraints
`Yr`	0..1	`ISODate`
`Tp`	0..1	`TaxRecordPeriod1Code`	18 codes
`FrToDt`	0..1	`DatePeriod2`

`TaxRecord2`#

Element	Card.	Type	Constraints
`Tp`	0..1	`Max35Text`	length 1–35
`Ctgy`	0..1	`Max35Text`	length 1–35
`CtgyDtls`	0..1	`Max35Text`	length 1–35
`DbtrSts`	0..1	`Max35Text`	length 1–35
`CertId`	0..1	`Max35Text`	length 1–35
`FrmsCd`	0..1	`Max35Text`	length 1–35
`Prd`	0..1	`TaxPeriod2`
`TaxAmt`	0..1	`TaxAmount2`
`AddtlInf`	0..1	`Max140Text`	length 1–140

`TaxRecordDetails2`#

Element	Card.	Type	Constraints
`Prd`	0..1	`TaxPeriod2`
`Amt`	1..1	`ActiveOrHistoricCurrencyAndAmount`
