UAE domestic AED transfer through UAEFTS with the CBUAE regulatory reporting code.
A payment initiation file for AE on the priority-payment rail, shipped in pain.001.001.03, pain.001.001.09, generated and checked by pain001 0.0.70. It is a synthetic example built from the public scheme rulebooks: no real party, account or bank guideline behind it.
Files#
| Edition | Payment file | ISO 20022 JSON twin | Provenance record |
|---|---|---|---|
pain.001.001.03 |
ae.uaefts.single.pain.001.001.03.xml | ae.uaefts.single.pain.001.001.03.iso.json | ae.uaefts.single.pain.001.001.03.provenance.yaml |
pain.001.001.09 |
ae.uaefts.single.pain.001.001.09.xml | ae.uaefts.single.pain.001.001.09.iso.json | ae.uaefts.single.pain.001.001.09.provenance.yaml |
The twin is the same payment in the ISO 20022 Registration Authority's JSON convention, lossless in both directions; its JSON Schema (2020-12) is published per edition: pain.001.001.03, pain.001.001.09. An agent can produce a twin that validates against the schema and hand it to the library to render the XML.
Run it in your browser#
Open this scenario in the demo: the pain001 library loads in a Python runtime in your browser, rebuilds the file from the 1 record(s) below, checks it against the anti-duplicate rulebook and the official XSD, and shows the JSON twin. Nothing leaves your machine.
The flat records the library rebuilds it from (the CSV pipeline's own column names):
id,date,nb_of_txs,ctrl_sum,initiator_name,payment_information_id,payment_method,batch_booking,service_level_code,requested_execution_date,debtor_name,debtor_account_IBAN,debtor_agent_BIC,charge_bearer,payment_id,payment_amount,currency,creditor_agent_BIC,creditor_name,creditor_account_IBAN,remittance_information,initiator_town_name,initiator_country_code,initiator_address_line,debtor_town_name,debtor_country_code,debtor_address_line,debtor_account_currency,creditor_town_name,creditor_country_code,purpose_code,regulatory_reporting_indicator,regulatory_reporting_country,regulatory_reporting_code,regulatory_reporting_info,payment_currency
AKB-20260921-01,2026-09-21T08:45:00,1,156000.00,Al Khaleej Building Materials LLC,AKB-FTS-260921-01,TRF,false,URGP,2026-09-21,Al Khaleej Building Materials LLC,AE307070122266392446102,EDCDAEL0,SHAR,AKB-2026-0921-001,156000.00,AED,UGENAE20,Emirates Steel Distribution,AE950889557780374725853,PO 2026-0812,Dubai,AE,Sheikh Zayed Road 220,Dubai,AE,Sheikh Zayed Road 220,AED,Abu Dhabi,AE,GDDS,CRED,AE,GDS,/BENEFRES/AE//GDS,AEDHow the library checked it#
- Official XSD: passed.
- ISO message definition rules: passed.
- Rail profile
ae-uaefts: passed. - Rail profile
purpose-mandate-ae: passed. - Rail profile
anti-duplicate: passed.
Confidence assumed: one detail rests on an assumption the record names; treat that detail with care.
Where the content comes from#
- Central Bank of the UAE, technical notes on transaction codes for balance-of-payments reporting (AUX700) (read 2026-09-11)
SHA-256 of each file is in its provenance record. Your bank's own usage guideline is not represented here: apply it privately with the library's overlay tooling.
